Product Description
Panasonic CX-411-P Photoelectric Sensor for industrial use.
Spec Detail
Item |
Specifications |
Product Number |
CX-411-P |
Part Number |
CX-411-P |
CE marking directive compliance |
EMC Directive, RoHS Directive |
Sensing range |
10 m 32.808 ft |
Sensing object |
ÃÂ12 mm ÃÂ0.472 in or more opaque object (Note) If slit masks (optional) are fitted, an object of ÃÂ0.5 mm ÃÂ0.020 in (using round slit mask) can be detected. |
Hysteresis |
- |
Repeatability(perpendicular to sensing axis) |
0.5 mm 0.020 in or less |
Supply voltage |
12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
Current consumption |
Emitter: 15 mA or less Receiver: 10 mA or less |
Output |
PNP open-collector transistor - Maximum sink current: 100 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 100 mA sink current), 1 V or less (at 16 mA sink current) |
Output:Output operation |
Switchable either Light-ON or Dark-ON |
Output:Short-circuit protection |
Incorporated |
Response time |
1 ms or less |
Operation indicator |
Orange LED(lights up when the output is ON) (incorporated on the receiver for thru-beam type) |
Stability indicator |
Green LED(lights up under stable light received condition or stable dark condition) (incorporated on the receiver for thru-beam type) |
Power indicator |
Green LED(lights up when the power is ON) (incorporated on the emitter) |
Sensitivity adjuster |
Continuously variable adjuster(incorporated on the receiver for thru-beam type) |
Automatic interference prevention function |
Two units of sensors can be mounted close together with interference prevention filters. (Sensing range: 5 m 16.404 ft) |
Protection |
IP67 (IEC) |
Ambient temperature |
- 25 to +55â -13 to +131â â (No dew condensation or icing allowed ), Storage: -30 to +70â -22 to +158â â |
