Delta DVP24ES200R-PLC

उत्पाद वर्णन

The Delta DVP24ES200R is a model from Delta's DVP-ES2 series of PLCs. Here are the detailed specifications:

General Specifications:

• Model: DVP24ES200R
• Manufacturer: Delta Electronics
• Series: DVP-ES2 Series
• Type: PLC (Programmable Logic Controller)

I/O Specifications:

• Total I/O Points: 24
  • Digital Inputs: 14 points
    • Input Voltage: 24VDC
    • Input Type: Sink/Source
    • Input Current: 7 mA @ 24VDC
    • Input Impedance: Approximately 3.3kÎ
    • Input Response Time: 10ms/5ms selectable
  • Digital Outputs: 10 points (Relay)
    • Output Type: Relay
    • Output Voltage: 24VDC / 220VAC
    • Output Current: 2A per point, 5A per common
    • Response Time: 10ms

Power Supply:

• Supply Voltage: 100-240VAC
• Power Consumption: 5W

Memory:

• Program Capacity: 16k steps
• Data Register: 10,000 words

Communication:

• Communication Ports: 1 RS-232, 1 RS-485
• Protocol Support: MODBUS ASCII/RTU, ASCII

Special Features:

• High-Speed Counters: 4 points (up to 10kHz)
• High-Speed Pulse Outputs: 2 points (100kHz)
• Timers/Counters: 200 timers/counters (including 10ms, 100ms, and 1s timers)
• External Interrupts: 6 points

Environmental Specifications:

• Operating Temperature: 0C to 55C
• Storage Temperature: -25C to 70C
• Humidity: 5% to 95% RH (non-condensing)
• Vibration Resistance: 10 to 55Hz, 0.75mm amplitude
• Shock Resistance: 10G for a duration of 11ms

Physical Specifications:

• Dimensions: 90mm x 60mm x 80mm
• Weight: Approximately 270g
• Mounting: DIN rail or panel mounting
