Kyocera KCG057QV1DC-G500 With Touch LCD Module

Product Description

The Kyocera 5.7-inch CSTN-LCD Module is a versatile and reliable display solution ideal for a variety of industrial and commercial applications. With a 320(RGB)240 QVGA resolution and a pixel density of 70 PPI, this display ensures clear and detailed visuals, making it suitable for control panels, medical devices, and other professional equipment. The active area measures 115.2(W)86.4(H) mm, providing sufficient screen space for data representation and interactive interfaces.

This module features CSTN (Color Super Twisted Nematic) technology, offering a vibrant 38% NTSC color range, while the RGB Vertical Stripe treatment enhances color sharpness. It operates in STN Normally Black mode, improving contrast and readability, and is transmissive, ensuring high visibility under a variety of lighting conditions.

With a luminance of 280 cd/m and a contrast ratio of 55:1, the display performs well in controlled environments. The viewing angles of 50/50/20/35 degrees offer decent visibility from various positions. Additionally, the response times of 180ms (Tr) and 170ms (Td) allow for smooth image transitions, critical for real-time data monitoring.

The module integrates easily into systems with its 20-pin parallel data interface and supports a frame rate of 75Hz. The CCFL backlight has a long lifespan of 75,000 hours, ensuring reliability over time. The module operates on a flexible 3.3/5.0V power supply and can handle operating temperatures between 0 and 60C, making it durable for industrial applications. Compact and efficient, this Kyocera LCD module weighs just 220g, making it a practical choice for a wide range of display needs.

This module is suitable for use in demanding environments such as industrial control panels, medical devices, and monitoring equipment.

Technical Precautions :-

• It is a front polarizer. It may damaged. Please be cautious. Dont scratch it.
• Always turn off the power supply when you are inserting or disconnecting it from the input connector.
• Wipe off water drop immediately as it may cause discoloration or spots.
• Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
• Do not try to open or modify the module assembly.
• At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
• Severe temperature condition may  result in different luminance, response time.

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, its imperative to recognize that errors may arise during this process. Despite our sincere efforts, its important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on our site  are the property of their respective owners.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!

Versatile Application Across Industries

The Kyocera KCG057QV1DC-G500 With Touch LCD Module is tailored for precision and reliability, making it a top choice in industrial automation panels, medical equipment screens, and commercial kiosks. Its 5.7-inch touch-enabled surface enhances user interaction, ensuring efficient operation in diverse use cases.


Durable Construction for Demanding Environments

Constructed from high-quality ABS and aluminium, the module provides exceptional durability even under rigorous conditions. With a compact form factor and a weight of 700 grams, it supports secure installation and consistent performance over time, reducing the risks of display failures.


Recommended Installation Practices

To maintain optimal performance and prevent accidental damage, it is strongly advised that installation is handled by professionals. Detailed installation guidelines help safeguard the module's integrity, ensuring long-lasting, trouble-free display operation.
