Panasonic EX-L221 Ultra-compact Laser Sensor

Product Description

Panasonic EX-L221 Ultra-compact Laser Sensor for industrial use.

Part Number	EX-L221
CE marking directive compliance	EMC Directive, RoHS Directive
Sensing range	45 to 300 mm 1.772 to 11.811 in (Note)The sensing range is specified for white non-glossy papar (100 x 100 mm 3.937 x 3.937 in) as the object.
Emission spot size (Typical)	1 mm 0.039 in or less (at a sensing distance of 300 mm)
Sensing object	1 mm 0.039 in or less (at a sensing distance of 300 mm)
Minimum sensing object (Typical)	Gold wire of 0.01 mm 0.0004 in (Note)Typical values when the sensitivity adjuster is optimally adjusted.
Hysteresis	20 % or less of operation distance
Repeatability	Perpendicular to sensing axis: 0.05 mm 0.0020 in or less
Repeatability (Typical)(perpendicular to sensing axis)	0.02 mm 0.0008 in or less (at 100 to 200 mm sensing distance) (Note)Typical values when the sensitivity adjuster is optimally adjusted.
Supply voltage	12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Current consumption	15 mA or less
Output	NPN open-collector transistor - Maximum sink current: 50 mA - Applied voltage: 26.4 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 50 mA sink current), 1 V or less (at 16 mA sink current)

Ultra-compact Design for Versatile Industrial Applications

The Panasonic EX-L221 sensor offers a compact footprint, simplifying installation even in confined spaces. Its advanced laser technology supports high-precision detection crucial for automation, assembly lines, and quality control across various industries. The ultra-compact design ensures reliable integration into both new and existing production setups.


Energy Efficient with Precise Performance

Designed for very low power consumption, the EX-L221 laser sensor delivers accuracy without compromising on energy use. Its 100% accuracy rate supports optimal operational efficiency and helps minimize errors in automated processes. This balance of energy efficiency and high performance is a key benefit to industrial users.
