Panasonic LX-111 Color Mark Sensor

Product Description

• The Panasonic LX-111 Color Mark Sensor, identified by part number ULX111-G, adheres to CE marking directives such as the EMC Directive and RoHS Directive. It provides a sensing range of 10 3 mm and a spot size of 1 x 5 mm when set at a distance of 10 mm. The supply voltage ranges from 12 to 24 V DC with a ripple of 10% or less.

  Output 1 of the sensor incorporates an NPN open-collector transistor. It has a maximum sink current of 50 mA and can handle an applied voltage of 30 V DC or less.. It includes short-circuit protection and supports various output operations such as Light-ON/Dark-ON and Consistent-ON/Inconsistent-ON modes. Output 2 also has similar specifications and operation, with an inverted function compared to Output 1.

  The Panasonic LX-111 Color Mark Sensor incorporates features like fine sensitivity adjustment, a timer function, and IP67 protection against dust and water ingress. It operates effectively in ambient temperatures ranging from -10 to +55 degrees Celsius and offers resistance to vibration and shock.

  Our engineers acts wisely inputted all the required details of this sensor in accordance with the datasheet. Nevertheless, its imperative to recognize that errors may arise during this process. Despite our sincere efforts, its important to remain cautious. Nonetheless, inaccuracies can still occur.

Exceptional Color Detection Accuracy

The Panasonic LX-111 Color Mark Sensor is renowned for its outstanding 100% detection accuracy, ensuring precise recognition of color marks on a range of materials. Ideal for industrial production lines, it eliminates errors and increases operational efficiency through reliable and consistent performance, even under challenging environmental conditions.


Robust Design and Energy Efficiency

Engineered for durability and longevity, the LX-111 is built with high-quality materials to withstand demanding industrial usage. Its innovative design leads to remarkably low power consumption, delivering a cost-effective solution for businesses seeking reliable automation components with minimal energy overhead.
