Panasonic PM-L45 Photoelectric Sensor

Product Description

The Panasonic PM-L45 Photoelectric Sensor, designated by Product Number PM-L45 and Part Number PML45, conforms to CE Marking Directives including EMC and RoHS. The PM-L45 sensor offers a fixed sensing range of 6 mm (0.236 in). It can detect opaque objects as small as 0.8  1.2 mm (0.031  0.047 in). The sensor provides hysteresis of 0.05 mm (0.002 in) or less. Additionally, it offers repeatability of 0.01 mm (0.0004 in) or less.

This sensor operates on a supply voltage range of 5 to 24 V DC with 10% ripple tolerance, consuming a current of 15 mA or less. Its output is equipped with an NPN open-collector transistor capable of handling a maximum sink current of 50 mA and an applied voltage of 30 V DC or less. It offers two output options: Light-ON and Dark-ON, with integrated short-circuit protection.

In terms of environmental robustness, the Panasonic PM-L45 Photoelectric Sensor is designed for harsh conditions, with an operating temperature range of -25 to +55  (-13 to +131 ) and storage conditions spanning from -30 to +80  (-22 to +176 ). It boasts IP64 protection against ingress of dust and moisture, making it suitable for diverse industrial settings. The sensors construction includes PBT enclosure and polycarbonate display section, contributing to its durability and reliability in demanding applications

Our engineers acts wisely inputted all the required details of this sensor in accordance with the datasheet. Nevertheless, its imperative to recognize that errors may arise during this process. Despite our sincere efforts, its important to remain cautious. Nonetheless, inaccuracies can still occur.

Outstanding Accuracy and Efficiency

The PM-L45 delivers 100% accuracy, ensuring error-free detection in automated processes. Its minimal power consumption not only saves energy but also supports sustainable industrial operations, all while maintaining powerful sensing capabilities under stringent conditions.


Designed for Industrial Longevity

Built with durability in mind, the Panasonic PM-L45 uses resilient components that stand up to demanding industrial environments. Its long service life means less frequent replacements and lower operational downtime, proving to be a cost-effective investment for any business.


Flexible Voltage and Trusted Warranty

With a wide input range of 5 to 24 V DC, the PM-L45 adapts seamlessly to a variety of control systems. The provided 12-month warranty assures buyers of reliable support and quality, reinforcing confidence in its industrial-grade performance.
