AUO G057VN01-V.2 LCD Module

Product Description

The AUO G057VN01-V.2 LCD Module is a high-brightness, compact display designed for industrial and embedded applications. With a 640480 (VGA) resolution and 141 PPI pixel density, it delivers sharp and detailed visuals in a small form factor. The active area of 115.2(W)86.4(H) mm ensures clear content display, while the antiglare treatment and 3H hard coating enhance durability and visibility in bright environments.

Featuring an impressive brightness of 700 cd/m (Typ.) and a contrast ratio of 800:1 (Typ.), this panel ensures excellent visibility even in high-ambient light conditions. The wide viewing angles of 80/80/70/70 (CR10) provide consistent image quality from different perspectives. With a response time of 15ms (Tr) / 10ms (Td), it offers smooth and responsive visuals for various applications.

Supporting 262K colors with 50% NTSC coverage, the RGB vertical stripe operating mode ensures color accuracy and uniformity. The panel uses a CMOS (1-channel, 6-bit) 33-pin connector for signal transmission, operating at a refresh rate of 60Hz. Powered by a 3.3V supply, it is energy-efficient and optimized for embedded systems.

Equipped with a WLED backlight featuring a 50,000-hour lifespan, the panel includes an integrated LED driver, simplifying power management and reducing external component requirements. Weighing 150g (Typ.) to 165g (Max.), it is lightweight yet robust.

Designed for extreme environments, the panel operates in temperatures from -30C to 85C, with a storage range of -30C to 85C, making it a reliable solution for industrial, automotive, and outdoor display applications.

This module is suitable for use in demanding environments such as industrial control panels, medical devices, and monitoring equipment.

Technical Precautions :-

• It is a front polarizer. It may damaged. Please be cautious. Dont scratch it.
• Always turn off the power supply when you are inserting or disconnecting it from the input connector.
• Wipe off water drop immediately as it may cause discoloration or spots.
• Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
• Do not try to open or modify the module assembly.
• At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
• Severe temperature condition may  result in different luminance, response time.
