Torisan TM121SV-02L01 LCD Module

Product Description

New Torisan TM121SV-02L01 LCD Module (TM121SV02L01) 12.1³ a-Si TFT-LCD panel is a compact display with an 800—600 (SVGA) resolution and a pixel density of 82 PPI. It features an active area of 246(W)—184.5(H) mm, providing a reliable visual experience for industrial and specialized applications. The panel operates in TN (Twisted Nematic) mode, which is Normally White and Transmissive, ensuring efficient brightness and color output.

With a luminance of 100 cd/m² (Typ.) and a contrast ratio of 150:1 (Min.), this panel offers moderate image clarity. However, its viewing angles of 45/45/10/30 (CR‰10) suggest that it is best viewed directly from the front. The response time of 30ms (Tr) / 20ms (Td) provides standard motion performance for applications where high-speed rendering is not a priority.

Supporting 262K colors with 42% NTSC coverage, the display delivers adequate color representation for basic graphical interfaces. The antiglare treatment enhances visibility by reducing reflections. The panel operates at a 60Hz frame rate and utilizes a Parallel RGB (1-channel, 6-bit) 41-pin connector for signal interface.

The Torisan TM121SV-02L01 LCD Module runs on a 3.3V power supply and is backlit by one CCFL tube with a 20,000-hour lifespan, although it does not include an integrated driver. The operating temperature range of -20C to 60C and a storage range of 0C to 50C make it suitable for controlled environments.

Technical Precautions :-

• • • It is a front polarizer. It may damaged. Please be cautious. Don™t scratch it.
    • Always turn off the power supply when you are inserting or disconnecting it from the input connector.
    • Wipe off water drop immediately as it may cause discoloration or spots.
    • Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
    • Do not try to open or modify the module assembly.
    • At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
    • Severe temperature condition may  result in different luminance, response time.

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it™s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it™s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on our site  are the property of their respective owners.
