LQ9D03B LCD Display Screen

1 INR/Piece

Get a Price/Quote

Product Details:

Surface Treatment Anti-glare / Hard coating 3H
Size Customize
Supply Voltage +5.0 V DC
Temperature Operating: 0oC to +50oC, Storage: -20oC to +60oC
Application Industrial
Standard Yes
Process Surface Mount Technology
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LQ9D03B LCD Display Screen Price And Quantity

Minimum Order Quantity 5 Piece
Price 1 INR/Piece

LQ9D03B LCD Display Screen Product Specifications

Installation Guideline Standard panel mounting with rear clamp or bezel
Material Metal
IP Rating N/A (Depends on enclosure)
Thickness 13.5 mm
Product Type LQ9D03B LCD Display Screen
Output Voltage N/A (Display only)
Weight Approx. 700 g
Usage Display Module for Industrial and Medical Equipment
Design Standard rectangular with mounting holes
Service Period Typically 50,000 hours (Backlight life)
Dimension (L*W*H) 247.0 mm x 168.0 mm x 13.5 mm
Color 256 Colors (8-bit) or more, Standard TFT LCD color
Finish Anti-glare Surface
Mounting Type Panel Mount
Input Voltage +5.0 V DC
Frequency 60 Hz (Frame frequency)
Technique Thin Film Transistor (TFT)
Processing Fully Assembled LCD Module
Humidity Storage: 10%~95% RH (Non-condensing), Operating: 20%~85% RH (Non-condensing)
Equipment Type Display Module
Standard Yes
Process Surface Mount Technology
Tolerance 0.5 mm
Size Customize
Temperature Operating: 0oC to +50oC, Storage: -20oC to +60oC
Supply Voltage +5.0 V DC
Application Industrial
Surface Treatment Anti-glare / Hard coating 3H

Viewing Angle 45 (Left/Right), 30 (Up/Down)
Active Area 192.0 mm x 144.0 mm
Front Bezel Not included (panel only)
Backlight Lifetime 50,000 hours (typical)
Orientation Landscape
Response Time 35 ms (typical)
Resolution 640 x 480 pixels (VGA)
Signal Interface Digital RGB (TTL) 31 pins
Connector Type Molex or equivalent standard
Pixel Pitch 0.3 mm x 0.3 mm
Contrast Ratio 150:1 (typical)
Backlight Type CCFL (Cold Cathode Fluorescent Lamp)
Luminance 130 cd/m2 (typical)
Power Consumption Approx. 6.6 W
Touchscreen Optional (not included by default)

LQ9D03B LCD Display Screen Trade Information

Supply Ability 100 Piece Per Week
Delivery Time 4-5 Days
Main Domestic Market All India

Product Description

Owing the multiple features of LQ9D03B LCD Display Screen like reduced radiation, energy efficient, longer life, better screen privacy, lighter weight, less eye strain, easy usability and good image quality, it is widely demanded and utilized in a number of versatile applications. This of LQ9D03B LCD Display Screen is extremely durable and we ensure its delivery within the promised time frame.

Main Export Market(s) : Worldwide

Payment Terms : Online

Versatile Display for Industrial Use

The LQ9D03B LCD module is tailored for industrial and medical environments where reliability and clarity are crucial. Its 640 x 480 VGA resolution, robust metal construction, and thin 13.5 mm profile allow for integration into a variety of control panels or diagnostic equipment. The display's 256 color support and CCFL backlight technology deliver consistent performance over extended operational periods.

Simple Installation and Custom Sizing

Designed with standard mounting requirements in mind, the LQ9D03B comes with optional rear clamp or bezel mounting for secure installation. Dimensions can be customized to suit unique application needs, while the Molex-compatible connector simplifies integration. The anti-glare, hard-coated surface ensures optimal readability even under challenging lighting conditions.

FAQ's of LQ9D03B LCD Display Screen:

Q: How is the LQ9D03B LCD display typically installed?

A: The LQ9D03B is designed for standard panel mounting, using either a rear clamp or a custom bezel. Its rectangular design includes mounting holes for secure and flexible installation in a variety of enclosures.

Q: What are the common applications for the LQ9D03B LCD screen?

A: This display module is ideal for use in industrial and medical equipment, such as machine interfaces, monitoring systems, and diagnostic instruments, where reliability and clear visual output are essential.

Q: What is the lifespan of the LQ9D03B's backlight, and how does it impact service periods?

A: The display's CCFL backlight has a typical lifetime of 50,000 hours, aligning with the recommended service period. This long lifespan minimizes maintenance needs and maximizes operational uptime in demanding environments.

Q: Can the LQ9D03B display be used in humid or variable temperature conditions?

A: Yes, it is rated for operation in temperatures ranging from 0C to +50C and can be stored between -20C and +60C. It can also operate safely in relative humidity levels of 20% to 85% (non-condensing).

Q: What signal interface and connector are used for this LCD module?

A: The module supports a Digital RGB (TTL) 31-pin signal interface and utilizes Molex or equivalent standard connectors for straightforward integration into existing systems.

Q: Is a touchscreen included with the LQ9D03B LCD display?

A: A touchscreen is optional for this model and is not included by default. If touch functionality is required, a compatible touchscreen can be integrated separately.

Q: What are the benefits of the LQ9D03B's anti-glare and hard-coated surface?

A: Its anti-glare and 3H hard-coated surface treatment enhances visibility under various lighting conditions and protects against minor scratches, ensuring long-term clarity and durability.
